Benefits for you:
Features:
| System maximum de voltage | 550/1000 |
| Maximum input strings | 6 |
| Maximum input current for each string | 16A |
| Maximum output switch current | 20A/32A |
| Number of inverter | 1 |
| Number of output strings | 1 |
| Nominal discharge current | 20KA |
| Maximum discharge current | 40KA |
| Voltage protection level | 2.8KV/3.8KV |
| Maximum continuous operating voltage Uc | 630V/1050V |
| MC4 Connectors/dc fuse/dc surge protector | Standard |
| Box material | PC/ABS |
| Installation method | Wall mounting type |
| Operating Temperature | -25°C-+55°C |
| Permissible relative humidity | 0-95%, no condensation |
Technical parameters
None
-
DC1500V CUSTOMIZED PV COMBINER BOXES FOR 16 STRINGS,20 STRINGS,24 STRINGS
